Pro Ject Phono Box MM/MC preamp with line output

Phono Box: Best buy classic for pure vinyl listening pleasure!

Today there aren’t many amplifiers that have a specific phono cartridge input. Phono Box is an ideal phono preamplifier for these HiFi systems and accepts both MM and MC cartridges. The analogue output of Phono Box can simply be connected to a line-input (AUX,…) of your amplifier.

Features

Preamplifier for MM or MC with switch on rear panel

Best buy classic

DC power supply (< 1 watt standby power)

Precise RIAA equalisation

Low noise ICs

Output stage with ultra-low impedance

Gold-plated RCA sockets

Small size for installation near recordplayer

Faceplate available in black and silver

Technical Specifications

Input impedance, MM 47 kohms/120 pF

Input impedance, MC 100 ohms / 120 pF

Gain, MM 40 dB

Output voltage typically 300 mV/1 kHz at 3 mV/1 kHz (MM input)

Gain, MC 60 dB

Output voltage typically 300 mV / 1 kHz at 0,3mV/1 kHz (MC input)

Max. output 9.5V (1kHz)

Noise floor, MM94 dBA

Noise floor, MC75 dBA

THD, MM0,01%

THD, MC0,05%

RIAA-equalisation curve accuracy 20 Hz – 20 kHz / max. 0,5 dB

Outboard power supply 18V / 200 mA DC, suitable for your country’s mains supply

Standby power consumption < 1 watts

Dimensions W x H x D 103 x 36 x 104 (115 mm with sockets)

Weight570 g
